Running 3forge with Kubernetes

This guide will take you through installing Kubernetes and deploying AMI on a Kubernetes node. For information about distributed deployment, please see this article instead.

Setting up Kubernetes

If you have already installed Kubernetes, feel free to skip to configuration.

This guide is for Windows systems using Chocolatey. The same actions can be performed in Unix/Linux systems with minor adjustments to command line syntax. You will also need to have Docker Desktop installed.

  1. If you don't already have it, install Chocolatey by pasting the following command into Powershell (in administrator mode):

    1
2
3
    Set-ExecutionPolicy Bypass -Scope Process -Force;
[System.Net.ServicePointManager]::SecurityProtocol = [System.Net.SecurityProtocolType]::Tls12;
iex ((New-Object System.Net.WebClient).DownloadString('https://chocolatey.org/install.ps1'))

  2. Install Minikube and kubectl with the command:

    1
    choco install minikube kubernetes-cli -y

  3. Start Docker Desktop, and run the following command in your Powershell:

    1
    minikube start --driver=docker

  4. Then, use the command kubectl get nodes. Your powershell should look something like this:

    You should now have a working Kubernetes cluster.

Configuration

  1. Create an Image Pull Secret (Optional). To allow your Kubernetes cluster to pull your private Docker image, you must create a secret containing your Docker Hub credentials.
    Run the following command, replacing the placeholders with your actual Docker Hub username and password or an access token.

    1
2
3
4
    kubectl create secret docker-registry regcred \
    --docker-server=https://index.docker.io/v1/ \
    --docker-username=[your docker hub name] \
    --docker-password=[your docker password or token]

  2. Create persistent directory on the Node. Before deploying k8s, you must create the following directory on the k8s node that will host the data. SSH into your chosen node and follow the steps:
    First, list the nodes and choose which one you want to use:

    1
    kubectl get nodes
    Launch a debug pod on the chosen node:
    1
    kubectl debug node/<YOUR_NODE_NAME> -it --image=ubuntu
    Create the directory as needed:
    1
    mkdir -p /host/mnt/data/ami-0
    And finally, exit:
    1
    exit

  3. Prepare Kubernetes manifests by creating a new folder named 'k8s' anywhere on your system, and add the following yaml files:

    This bundles all Kubernetes resources together, which you can deploy with a single command.

    1
2
3
4
5
6
7
8
    apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

resources:
- statefulSet.yaml
- services.yaml
- storageClass.yaml
- persistentVolume.yaml

    This defines a StorageClass for local volumes.

    1
2
3
4
5
6
7
8
    # Storage Class
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
    name: ami-storage-class
provisioner: kubernetes.io/no-provisioner # Change to cloud as needed
volumeBindingMode: WaitForFirstConsumer
reclaimPolicy: Retain

    This defines local PersistentVolume (PV) that maps to the directory you created on the node (not necessary if using cloud storage).

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
    # Persistent Volume (Create more as needed)
apiVersion: v1
kind: PersistentVolume
metadata:
    name: ami-pv-0
spec:
    capacity:
        storage: 5Gi
    volumeMode: Filesystem
    accessModes:
        - ReadWriteOnce
persistentVolumeReclaimPolicy: Retain
storageClassName: ami-storage-class # Must match the name in statefulset.yaml
local:
    path: /mnt/data/ami-0
    nodeAffinity: # Define PV on a specific node
    required:
        nodeSelectorTerms:
        - matchExpressions:
            - key: kubernetes.io/hostname
            operator: In
            values:
            - docker-desktop # Change to your node name

    This creates two types of services for network access:

    • Headless Service: provides unique DNS entry for each pod within the cluster for stable internal communication.

    • NodePort Service: exposes pod individually to external traffic on a static port on the host node.

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
    # Headless Service for internal communication
apiVersion: v1
kind: Service
metadata:
    name: ami-headless-service
spec:
    clusterIP: None # makes the service "headless".
selector:
    app: ami
ports:
    - protocol: TCP
    port: 80 # Port for internal communication
    targetPort: 33332
---
# NodePort Service (create more as needed)
apiVersion: v1
kind: Service
metadata:
    name: ami-instance-0-service
spec:
    type: NodePort
    externalTrafficPolicy: Local
    selector:
        statefulset.kubernetes.io/pod-name: ami-instance-0
ports:
    - port: 80
    targetPort: 33332
    nodePort: 30080 # NodePort for external access

    A StatefulSet is used to manage stateful applications that provide each pod with a persistent and unique network identifier (e.g., ami-instance-0, ami-instance-1) and dedicated storage.

     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
        # Stateful Set
    apiVersion: apps/v1
    kind: StatefulSet
    metadata:
        name: ami-instance
    spec:
        selector:
        matchLabels:
            app: ami # Must match the labels below.
        serviceName: "ami-headless-service"
        replicas: 1
        template:
            metadata:
            labels:
                app: ami
            spec:
                imagePullSecrets:
                    - name: regcred
                subdomain: ami-headless-service # Must match the serviceName.
                initContainers: # Tmp container for copying persisted files
                    - name: init-default-files
                    image: ami-image # whatever your AMI docker image is called.
                    command:
                        - "sh"
                        - "-c"
                        - |
                        set -e
                            echo "Initializing default directories..."
                            for dir in config data hdb lib persist scripts web_resources; do
                                if [ ! -d "/init-data/${dir}" ]; then
                                    echo "Copying default '${dir}' directory..."
                                    cp -r "/ami/amione/${dir}" /init-data/
                            fi
                            done
                            echo "Initialization complete."
                    volumeMounts:
                    - name: ami-local-storage
                    mountPath: /init-data
                containers:
                - name: ami-container
                image: franc1sd/ami:dev
                imagePullPolicy: IfNotPresent
                ports:
                    - containerPort: 33332
                volumeMounts: # mount more directories as needed.
                    - name: ami-local-storage
                    mountPath: /ami/amione/config
                    subPath: config
                    - name: ami-local-storage
                    mountPath: /ami/amione/data
                    subPath: data
                    - name: ami-local-storage
                    mountPath: /ami/amione/hdb
                    subPath: hdb
                    - name: ami-local-storage
                    mountPath: /ami/amione/lib
                    subPath: lib
                    - name: ami-local-storage
                    mountPath: /ami/amione/persist
                    subPath: persist
                    - name: ami-local-storage
                    mountPath: /ami/amione/scripts
                    subPath: scripts
                    - name: ami-local-storage
                    mountPath: /ami/amione/web_resources
                    subPath: web_resources
        volumeClaimTemplates:
        - metadata:
            name: ami-local-storage
        spec:
            accessModes: ["ReadWriteOnce"]
            storageClassName: "ami-storage-class" # Must match the name in storage.yaml.
            resources:
                requests:
                    storage: 5Gi # Adjust as needed.

  4. Run the following command from the k8s directory using kustomize:

    1
    kubectl apply -k .

  5. Check the status of your pods. You should see them being created sequentially, from ami-instance-0 to ami-instance-2:

    1
    kubectl get all

Cleanup

Option 1: Delete only the workloads (keep the instance-volume bind). To do this, run the following commands from the k8s directory to delete only the services and pods:

1
2
3
kubectl delete service/ami-headless-service
kubectl delete service/ami-instance-0-service
kubectl delete statefulset/ami-instance
Option 2: Complete Deletion (use with caution). To delete ALL the resources created by this guide, run the following command. Your data stored in /mnt/data/ami-0 will be orphaned but will remain on the node's disk:
1
kubectl delete -k .
